Sunrise Medical
Sunrise Medical Quickie QS5 X Manual Wheelchair
Overview:
The Sunrise Medical Quickie QS5 X Manual Wheelchair offers a unique blend of effortless folding, frame rigidity and ultra-lightweight handling. With its FreeFold cross-brace system and optional locking mechanism, it reduces folding effort by over 40% while delivering a ride quality that rivals rigid frames.
Description
The Sunrise Medical Quickie QS5 X Manual Wheelchair redefines folding wheelchair performance through advanced FreeFold technology – an innovative folding geometry that lowers resistance during folding and unfolding. This makes everyday handling easier, especially when storing or lifting the chair into a vehicle.
Made from heat-treated 7000-series aluminium, the oval-tubed frame and cross-brace deliver exceptional rigidity with minimal flex. At just 7.3 kg transport weight (fixed-front version), it’s the lightest aluminium folding box frame in its class.
The Quickie QS5 X is available in both fixed front and swing-away frame versions. Fixed front provides stability and support, while the swing-away option enhances transfers and reduces pack size. Additional comfort features include ergonomic touch points for lifting, a redesigned knee lever wheel lock for reduced hand strength, and optional removable LED lighting for visibility.
The chair’s castor system is fully adjustable to maintain straight tracking and reduce energy loss. Multiple personalisation options allow the frame, handrims, upholstery and anodised components to reflect each rider’s unique style.
Who it’s for
- For clients seeking a lightweight folding wheelchair that combines transport ease with rigid-like performance.
- For therapists supporting clients who require a strong, stylish and energy-efficient folding wheelchair for daily use.
Key features
- FreeFold cross-brace – reduces folding effort by over 40%
- Heat-treated 7000-series aluminium frame – strong and ultra-light
- Fixed-front or swing-away frame – supports different positioning and transfer needs
- Transport weight from 7.3 kg – easy to lift and store
- Patented castor system – improves tracking and propulsion efficiency
- Ergonomic touch points – reduce wrist strain during lifting or transfer
- Optional LED lighting – removable, rechargeable lights for added visibility
- Refined design – hidden adjustments and sleek aesthetic
| Specification | Details |
|---|---|
| Safe Working Load (SWL) | 136 kg |
| Base Length | 111.3 cm (44”) |
| Seat Width | 34 cm – 52 cm (13” – 20.5”) |
| Seat Depth | 34 cm – 50 cm (13” – 19.75”) |
| Front Seat Height | 36 cm – 54 cm (14” – 21.25”) |
| Rear Seat Height | 35 cm – 52 cm (13.75” – 20.5”) |
| Backrest Height | 25 cm – 50 cm (10” – 19.75”) |
| Backrest Angle | –3° to +15° |
| Frame Angle | Swing-away: 70°, 80°, 90° Fixed front: 75°, 85° |
| Camber | 0°, 2°, 4° |
| Front Castor | 10.2 cm – 17.8 cm (4” – 7”) |
| Rear Wheel | 55.9 cm – 66 cm (22” – 26”) |
| Frame Material | Aluminium |
| Total Weight | 9 kg |
| Transport Weight (excl rear wheels) | Swing-away: 7.5 kg Fixed front: 7.3 kg |
| Warranty | Limited lifetime on frame; 1 year limited on components |
| Standard | ISO 7176-19 / WC19 AS/NZS 3695 |
| Transit Options | Transit approved |
| ARTG Certificate | 100167 |
| Compatible with Power Assist | Yes |
Sunrise Medical Quickie QS5 X Manual Wheelchair Brochure
