Key features

Description

Ready for transportation
Integrated anchor brackets for carrying people with limited mobility in a vehicle. To save space, the rehab buggy can also be folded in a few simple steps.

Tilt activation mechanism
The tilt activation mechanism is located next to the push bar for easy use.

Changing the perspective
Depending on the situation, the sitting unit can be readily installed in or against the direction of travel.

Create your own inlay
An inlay created solely by the user’s preferences not only brightens the product, but also enhances hygiene. The cutting pattern as well as the necessary sewing instructions are free of charge.

Specifications

Details	Size 1	Size 2
Seating Unit
Seat Back Length	410 mm – 610 mm	560 mm – 700 mm
Seat Depth	190 mm – 310 mm (140 mm Shortened)	240 mm – 400 mm
Seat Width	200 mm – 300 mm	260 mm – 350 mm
Lower Leg Length	190 mm – 310 mm (122 mm Shortened)	200 mm – 370 mm
Weight	7.5 kg	9.5 kg
Back Angle	80° – 180°	80° – 180°
Seat Tilt	-10° To 40°	-10° To 40°
Maximum Load	40 kg	40 kg
Outdoor Mobility Base (Stroller)
Weight Of Outdoor Mobility Base (Stroller)	10.5 kg	10.5 kg
Overall Width	595 mm	665 mm
Overall Length	1110 mm	1110 mm
Seat Tilt	-40° To +10° Or -10° To +40°	-40° To +10° Or -10° To +40°
Maximum Load Of Outdoor Mobility Base	55 kg	55 kg
Indoor Mobility Base
Weight Of Indoor Mobility Base	6.4 kg – 6.6 kg	6.4 kg – 6.6 kg
Overall Width	450 mm	450 mm
Overall Length	620 mm – 780 mm	620 mm – 780 mm
Seat Tilt	-10° – 35°	-10° – 35°
Maximum Load Of Indoor Mobility Base	50 kg	50 kg

Videos

Downloads

Kimba User Manual

Kimba Flyer
